Sectional Model 2042

Duty Rating: Extra Heavy-Duty
Insulation/R-Value: 19.4
Layers: 3
Warranty: 10-Year
Price: $$$

download brochure

Sectional Model 2042

This Extra Heavy-Duty top-of-the-line high R-value door is constructed using 20-Gauge exterior steel that is foamed-in-place with polyurethane insulation which creates a strong monolithic panel that is energy efficient.

Maximum R-value
Our polyurethane insulation provides the best R-Values per inch when compared to other common types of sectional door insulation.

Security Strength
20-gauge steel exterior skin with the added strength of foamed-in-place polyurethane insulation provide maximum strength and security for your opening



Section Profile
Commercial Garage Door Model 2042 Flush Stucco Panel Profile

Flush Stucco

Construction
Steel Insulation Steel Construction

Steel + Insulation + Steel

Track
All Amarr Doors are available with both
2″ or 3″ track in Standard Lift, High Lift, Vertical Lift,
Low Headroom, and Follow the Roof Pitch. Custom track configurations are also available. For drawings and more information, please visit our downloads website.
Hardware
Amarr hardware includes minimum
14-gauge galvanized steel hinges and 13-gauge galvanized steel track brackets. All rollers have
minimum 10-ball bearings.
Springs
Torsion springs are oil tempered, helical wound and custom computed for each door for a minimum 10,000 cycle life. Optional springs are available up to 100,000 cycle life.
Windows
Window Panel Option - 24x12

24″ x 12″ Insulated

26″ x 13″ Insulated

commercial garage door model 2042 window option

24″ x 6″ Insulated

Window Panel Option - Full View

Full View

Garage Door Window Type - Perforated Full View

Perforated Aluminum Full View

Colors
  • True White



Specifications
R-VALUE19.4
STEEL THICKNESS20/27 Ga.
PANEL DESIGNFlush
STEEL EMBOSSMENTStucco
CONSTRUCTION LAYERSThree
MAX STD WIDTH40’2″
MAX STD HEIGHT26’1″
DOOR THICKNESS2″ (5.1cm)
