Rolling Slat Model 4100

Duty Rating Extra HD or Heavy-Duty
Insulation/R-Value 6.29
Layers 3
Warranty 2-Year Limited
Price $$$$

download brochure

Rolling Slat Model 4100

In applications where climate control is a must, the 4100 Series provides maximum energy efficiency by using a polyurethane core that is foamed-in-place between the exterior and interior galvanized steel skins.

MAXIMUM R-VALUE
Our insulation has an R-value of 6.29 and is of the highest quality available with a flame spread not greater than 25 and smoke generation less than 50.

PRODUCT FLEXIBILITY
The Model 4100 is available in replaceable 22, 20, or 18 gauge insulated flat slats.



Finishes
  • White
  • Gray
  • Tan
Operators
Chain Hoist

Chain Hoist

Electric Operator Opener

Electric Operator

Slat Detail
Optional Windows

Optional Windows

Slat Profile
Insulated Slat

Insulated Slat

Technical Features
Cast Iron Gears

Cast Iron Gears

Structural Steel Angle Guides

Structural Steel Angle Guides

Optional Plated Steel Bottom Bar Slide Locks

Optional Plated Steel Bottom Bar Slide Lock

Electric Operator Opener

Optional Motor Operation

Foamed In Place Polyurethane Insulation

Foamed in place Polyurethane Insulation



Specifications
STEEL SLAT GAUGE OPTIONS22, 20 & 18 ga
MAX DOOR WIDTH30’4″
MAX DOOR HEIGHT24’4″
GUIDESStructural Steel Angle
WIND LOAD AVAILABLEYes
