Sectional Model 2002/2012/2022

Duty Rating Extra Heavy-Duty
Insulation/R-Value N/A – 7.0
Layers 1, 2, or 3
Warranty 10-Year
Price $$$

download brochure

Sectional Models 2002/2012/2022

The Model 2002 combines Extra Heavy-Duty strength with versatility. The deep ribbed 20 gauge steel sections can be factory- or field-modified with CFC-free polystyrene insulation that features a nylon or steel backer to fit the needed application.

STRENGTH SECURITY
20-gauge steel doors with a deep ribbed profile provide maximum strength and security

PRODUCT FLEXIBILITY
The Model 2002 is available un-insulated, insulated, or insulated with a steel backer to fit most project requirements



Section Profile

Ribbed Stucco

Colors
  • Commercial White
Construction
Single Layer Steel

Model 2002 – Single Layer Steel

Double-Layer Steel + Insulation

Model 2012 – Double Layer Steel + Insulation

Triple Layer Construction

Model 2022 – Triple Layer Steel + Insulation + Steel

Windows
Window Panel Option - 24x12

24″ x 12″ Insulated

Window Panel Option - Full View

Full View

Garage Door Window Type - Perforated Full View

Perforated Aluminum Full View

Commercial Garage door Window Option Louvered

Louvered Aluminum Full View

24″ x 6″



Specifications200220122022
R-VALUEN/A7.07.0
STEEL THICKNESS20 ga20 ga20/25 ga
PANEL DESIGNDeep RibbedDeep RibbedDeep Ribbed
STEEL EMBOSSMENTSmoothSmoothSmooth
CONSTRUCTION LAYERSOneTwoThree
MAX STD WIDTH26’2″26’2″26’2″
MAX STD HEIGHT26’1″26’1″26’1″
DOOR THICKNESS2″ (5.1cm)2″ (5.1cm)2″ (5.1cm)



Have questions about this product?
